Omnitronic UHF1 wireless microphone
Omnitronic UHF1 wireless microphone
Additionally, the system offers a quality that has never been available in this price range before. In this way, the diversity-reception-system provides the best possible reception without interruptions or loss of quality. There are also systems with double or fourfold reception, for those wanting to use more than one microphone. These multi-receptors are not only space-saving.
Beside the single outputs for every microphone, they also feature a mix output, combining all microphones in one output, where the volume can be controlled. This way, mixer channels can be reduced or the entire mixer even omitted.
There is a matching pocket transmitter with lavalier microphone for every available frequency. The systems have a range of up to 50 meters with a battery life of 12 hours (two standard AA batteries are sufficient).
| Coverage: | 50 m (with line-of-sight) |
| RF power output: | 10 mW |
| Modulation method: | F3F |
| Frequency response: | 40 Hz - 18 kHz |
| S/N ratio: | >105 dB |
| Selectivity: | >80 dB |
| T.H.D.: | <0.5 % at 1 kHz |
| Audio outputs: | 400 mV, 2.2 kohms (XLR, bal.) |
| 200 mV, 2.2 kohms (6.3 mm jack, unbal.) | |
| Power supply | |
| Receiver: | 230 V AC, 50 Hz ~ via supplied power unit |
| Power consumption: | 10 W |
| Microphone: | 2 x 1.5 V battery, type AA |
| Battery life: | approx. 10 hours |
| Dimensions, weight: | |
| Receiver: | 155 x 210 x 45 mm (WxDxH), 1 kg |
| Microphone: | 50 x 265 mm (DxL), 280 g |
